Steel Connection Design
Priced at RM 237.60 Per 1 Unit and Inclusive of 8% SST Tax
A software for engineers to design steel connections encompassing fixed, pinned, base plate, and cladding support connections. The fixed connection comprises two types, one without haunch and another with haunch. And this fixed connection is for universal beam to universal column flange connection. The pinned connection can be designed either with one shear plate or two shear plate. A maximum of two bolt columns can be included. The base plate connections is applicable for I, C, T, Circular Hollow Sections, and Rectangular Hollow Sections. The cladding support connections involves designing the connection cleats and bolts for both purlin and flange brace connections.
Version 2 - Improvements To Version 1Version 2 has so much improvements in generating the figures in the drawing panel in such that it does not use bitmaps to generating figures but rather code generated. In addition, it has now 3D Viewer capabilities so thatyou can view the model in 3D. Another capability, is that you can generate and print dxf drawings. And finally, after calculation process, you can print calculations in word document.
Important Note : To install version 2, please uninstall version 1 first.
Capabilities of the software:
The software does have the following capabilities:
a. 3D Viewer
b. Print DXF drawings
c. Print calculations in Word Document
d. Print snapshot of current view
See snapshots and videos below. Visit the Shop tab page to purchase.
